EPFU (Enhanced Performance Fiber Unit) Air Blown Cable is a type of fiber optic cable designed for easy installation and flexibility in telecommunications networks. It is part of the air-blown fiber (ABF) technology, which uses compressed air to blow lightweight fiber optic cables into ducts. This type of cable is particularly useful for rapid deployment and easy network upgrades or expansions and mainly used in FTTH, FTTD and MDU networks.
2,4,6,8 and 12 fibres options.
Stable structure, good mechanical and temperature
Designed with special grooves to adavance blowing distance
Light weight and proper stiffness, repeat installation
Designed with no gel, easy stripping and handling.
Better costs advantage compared to traditional product.
Complete accessories, less manpower, lower installation time.
FTTx
Telecommunication
Optical Fiber Communication
| Items | 2 Fibres | 4 Fibres | 6 Fibres | 8 Fibres | 12 Fibres | |
|---|---|---|---|---|---|---|
| Outer Diameter (mm) | 1.15（±0.05）mm | 1.15（±0.05）mm | 1.35（±0.05）mm | 1.50（±0.05）mm | 1.65（±0.05）mm | |
| Weight (g/m) | 1.0 | 1.0 | 1.3 | 1.8 | 2.2 | |
| Min Bend radius (mm) | 50 | 50 | 60 | 80 | 80 | |
| Temperature(℃) | Storage | -30 ~ +70 | -30 ~ +70 | -30 ~ +70 | -30 ~ +70 | -30 ~ +70 |
| Operation | -30 ~ +70 | -30 ~ +70 | -30 ~ +70 | -30 ~ +70 | -30 ~ +70 | |
| Installation | -5 ~ +50 | -5 ~ +50 | -5 ~ +50 | -5 ~ +50 | -5 ~ +50 | |
