The field assembly SC/APC fiber fast connector have been factory-polished,it removes any requirement for epoxy, adhesives or costly curing ovens and polishing and fiber ederface inspection. The fast Connector offers convenience in assembling and strong stability, it can provide a quick and easy termination of fibers in the field.
No epoxy and polishing required Quick and easy fiber termination
Precision mechanical alignment insures low insertion loss Low insertion loss
FTTH Solution CATV
Fiber optic data transmission
| Connector Type | SC | Polishing | APC |
|---|---|---|---|
| Ferrule | Ceramic | V Groove | Plastic |
| Cable Diameters | 0.9/2.0/3.0mm Simplex cable | Dimension | 55mm |
| 2×3 FTTH Drop Cable | |||
| Insertion Loss | ≤0.3dB(typical) | Return Loss | APC≥50dB |
| ≤0.5dB(Max) | |||
| Tension Strength | ≥30N | Operating Temperature | -40°C~+75°C |
