The NSN boot LC patch cord is available with 45/ 90 degrees and straight duplex or 360 degree any direction angle Uniboot to connect the Nokia Simens RRH panels.The fiber cable has corrugated steel armored or non-armored for option with UV resistance jacket.
High temperature stability, low insertion loss
Provides moisture and dust protection for use in harsh industrial environments
Easy operation, reliable and cost-effective installation
Available in single mode and multimode styles to work with any common fiber type
Telecom networks
Outdoor FTTP, FTTA
Broadband
| Item | Parameter |
|---|---|
| Connector Type | LC Uniboot Connector With Flex NSN boot |
| Fiber Type | Single mode 1310/1550 or multimode 850/1300 |
| Insertion Loss | SM ≤0.2dB MM ≤0.2dB |
| Return Loss | SM ≥50dB MM ≥35dB |
| Repeatability | ≤0.1 |
| Interchangeability | ≤0.2dB |
| Durability | ≤0.2dB |
| Cable Diameter | 7.0mm |
| Fiber Length | Customized |
| Operating Temperature | -45~85℃ |
| Storage Temperature | -45~85℃ |
