GYXTC8S outdoor fiber cable with fibers are positioned in the loose tubes, while the loose tubes strand together around metallic central strength member into a compact and circular cable core, and the water-blocking materials are distributed into interstices of it. After a PSP/APL is applied around the cable core, this part of cable accompanied with the stranded wires as the supporting part are completed with a PE sheath to be a figure-8 structure.
Good mechanical and temperature performance
High strength loose tube that is hydrolysis resistant
pecial tube filling compound ensure a critical protection of fiber
Crush resistance and flexibility
PE/LSZH sheath protects cable from ultraviolet radiation
Outdoor Aerial and Self-supporting
| Cable Count | Out sheath Diameter(MM) | Weight(KG) | Minimum allowable Tensile Strength(N) | minimum allowable Crush Load(N/100mm) | Minimum Bending Radius(MM) | Storage temperature(°C) | |||
|---|---|---|---|---|---|---|---|---|---|
| short term | long term | short term | long term | short term | long term | ||||
| 6 | 3.0×9.8 | 54 | 1000 | 200 | 1000 | 200 | 20D | 10D | 20 |
| 12 | 3.0×9.8 | 54 | 1000 | 200 | 1000 | 200 | 20D | 10D | 20 |
| 24 36 42 | 7.0×14.5 | 210 | 3000 | 1000 | 3000 | 1000 | 20D | 10D | 20 |
| 48 | 7.0×15.5 | 210 | 3000 | 1000 | 3000 | 1000 | 20D | 10D | 20 |
| 72 | 7.0×15.5 | 245 | 3000 | 1000 | 3000 | 1000 | 20D | 10D | 20 |
| 144 | 7.0×15.5 | 285 | 3000 | 1000 | 3000 | 1000 | 20D | 10D | 20 |
